Fire-Rated Metal Door
Fire-Rated Metal Door
Starting at $350.00
Description
Fire-Rated Steel Doors for Commercial and Industrial Use
Uniteddoors is an authorized Warnock Hersey / Intertek (WHI) fire-labeled facility, allowing us to modify, re-certify, and apply labels to fire-rated doors and frames. We are also UL-certified to cut, re-certify, and label fire-rated glazing materials. Our facility is subject to regular inspections to ensure all modifications comply with Intertek and UL listing requirements. All products are tested in accordance with applicable NFPA codes and standards.
Product Features
- Fire ratings available up to 3 hours, with WHI/ITS mylar label applied
- 1-3/4” thick, non-handed construction with reversible hinge plates
- Interlocking seam design for increased strength and durability
- Factory-applied rust-inhibiting primer (standard finish only)
- Fire-rated glazing options available for vision lites
| Level |
Heavy Duty, SDI Level 2 – 18-Gauge Steel Face Sheets – (16 Ga. Available) |
|---|---|
| Core |
Rigid Honeycomb Core or Polystyrene Core |
| Door Thickness |
1-3/4" Standard |
| Handing |
Non-Handed Design; Reversible Hinge Plates |
| Sizes |
Standard Widths up to 4'0", Height to 8'0" (Custom Sizes Available) |
| Edges |
Square Hinge and Lock Edges (Beveled Edges Available) – Full Height, Epoxy Filled Mechanical Interlock Edges |
| Reinforcements |
Heavy Gauge Door Closer and Hinge Reinforcements |
| Channels |
14-Gauge Inverted Top and Bottom Channels, Optional Flush Top Cap |
| Door Finish |
Factory-Applied, Baked-On, Rust Inhibiting Gray Primer (No Special Color Options) – Not intended to be a finish coat. It is recommended that finish paint (top coat) be applied after installation |
| Standard Preps |
161 (cylindrical lock), 86 Edge (mortise lock), Deadbolt, RPD (blank edge, panic reinforced) |
| Optional Preps |
Continuous Hinge Application (Undersized Width), Exit Device Trim, Lite and Louver Cutouts |
| ANSI Standards |
Meets or Exceeds Standards for ANSI 250.4 and ANSI 250.8 |
| Fire-Rating |
WHI / ITS up to 3-hour Fire-Rating, Positive Pressure and “S” Smoke included |
| Approvals |
Certified for Compliance with NFPA 80, NFPA 252, UL 10B, UL 10C |
| Buy American Act Compliance |
Meets Buy American Act |
| Mfg. Hinge/Lock Locations |
Steelcraft, Baron, Ceco, Curries, Mesker, Republic, Pioneer, Deansteel, Custom Locations |
